NZXT H7 Flow Mid-Tower ATX Airflow Case - White | CM-H72FW-01

AED 499.00
AED 550.00

In stock

SKU
CM-H72FW-01
  • USB 3.2 Gen 1 & Gen 2 | 3.5mm Audio Jack
  • Supports CPU Coolers up to 7.8" Tall
  • ATX, M-ATX, M-ITX, E-ATX Support
  • 2 x 2.5" & 2 x 2.5/3.5" Drive Bays
  • Supports GPUs up to 16.1" Long
  • Steel Frame & Ultra-Clear Glass
  • 1.3" Cable Management Space
  • 7 x Expansion Slots
heart
Wish List
chart-bar
Compare

NZXT H7 Flow Mid-Tower ATX Airflow Case - White | CM-H72FW-01

-

The H7 Flow revolutionizes GPU cooling in a classic mid-tower form factor. Its vertical PSU layout allows space for 3 x 120mm bottom fans, offering efficient cooling without expanding the case footprint.

Dedicated GPU Cooling
Supports three bottom-mounted 120mm fans for direct GPU cooling in a narrow mid-tower footprint.

Out-of-the-Box Performance

Comes equipped with 3 x 120mm front-mounted fans for exceptional out-of-the-box cooling performance.

Optimized for Airflow
High-performance mesh panels maximize airflow for both intake and exhaust, as well as filter dust.

Large Radiator Support
Supports up to a 420mm radiator in front and 360mm radiator up top for max cooling potential.

Easily Manage Cables
Intuitive cable management system with wide channels, built-in hooks, and included straps for easy routing.

10-Fan Capacity
Capacity for up to 10 fans in total: 3 up top, 3 in front, 3 on bottom, and 1 in the rear.

Top I/O Ports
Conveniently access 2 x USB-A and 1 x USB-C ports located on the top panel.

Tool-less Panel Access
Tool-less access to the front, top, and side panels makes building and upgrading a breeze.



SKU CM-H72FW-01
GTIN 5056547205519
Specifications

Motherboard Support

E-ATX (Up to 27.7mm), ATX, Micro-ATX, Mini-ITX

Enclosure Type

Mid-Tower

Case Material

SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black)

Dimensions

Height (with feet): 544 mm, Width: 244 mm, Depth: 468 mm, Weight: 11.13 kg

CPU Cooler Height

Up to 185 mm

GPU Length

Up to 410 mm

PSU Length

Up to 200 mm

Cable Management

Up to 34.5 mm

Top Mounted Radiator & Fan

Up to 57 mm

Front I/O Ports

USB 3.2 Gen 1 Type-A: 2, USB 3.2 Gen 2 Type-C: 1, Headset Audio Jack: 1

Expansion Slots

Standard: 7, Vertical: 0

Drive Bays

2.5": 2+2, 3.5": 2

Fan Support

Front: 3 x 120 mm / 3 x 140 mm, Top: 3 x 120 mm / 2 x 140 mm, Rear: 1 x 120 mm / 1 x 140 mm

Filters

High-Performance Mesh

Radiator Support

Front: Up to 420 mm, Top: Up to 360mm, Rear: Up to 140mm

Fan Specs

Model: F120Q Airflow Fan (Case Version), Speed: 1,350 ± 150 RPM, Airflow: 60.2 CFM, Static: 1.05 mm - H2O, Noise: 24.1 dBA, Fan Connector: 3-pin

Warranty

2 Years

Model Number

CM-H72FB-01 (Black) / CM-H72FW-01 (White)

UPC

810074845557 (Black) / 810074845564 (White)

EAN

5056547205502 (Black) / 5056547205519 (White)



Brand NZXT
Weight 13.000000
