SilverStone ST85F-GS 850W 80 Plus Power Supply

AED 500.00

In stock

SKU
SST-ST85F-GS

■ Compact design with a depth of 140mm for easy integration (V2.0)

■ Compact design with a depth of 150mm for easy integration (V1.0)

■ Strict ±2.5% voltage regulation and low ripple & noise (V2.0)

■ Strict ±3% voltage regulation and low ripple & noise (V1.0)

■ 24/7 continuous power output with 40℃ operating temperature

■ 80 PLUS Gold certification

■ 100% modular cables

■ Class-leading single +12V rail

■ Silent running 120mm fan with 18dBA minimum

heart
Wish List
chart-bar
Compare

SilverStone ST85F-GS 850W 80 Plus Power Supply

-

■ Compact design with a depth of 140mm for easy integration (V2.0)

■ Compact design with a depth of 150mm for easy integration (V1.0)

■ Strict ±2.5% voltage regulation and low ripple & noise (V2.0)

■ Strict ±3% voltage regulation and low ripple & noise (V1.0)

■ 24/7 continuous power output with 40℃ operating temperature

■ 80 PLUS Gold certification

■ 100% modular cables

■ Class-leading single +12V rail

■ Silent running 120mm fan with 18dBA minimum



Designed for 80 PLUS Gold level of efficiency to reduce wasted heat

Regulation and low ripple & noise performance for high stability.

100% modular cable design for use with short cable kit such as SilverStone’s PP

140mm depth sets new standard for high wattage PSUs with modular cables.

Built-in 120mm fan has excellent airflow and low noise, perfect for quiet home or office use.

Strider Gold S PSUs are the first power supply models in the world to include flat 24pin cables. This cable offer much greater flexibility for tighter folding and superior cable management.

Powerful single +12V rail design, perfect for future high-end component upgrades or overclocking.





SKU SST-ST85F-GS
GTIN 4710007220511
Specifications
Model No.
SST-ST85F-GS (V2.0)
Max. DC Output
850W
Load Range (V2.0)
  +3.3V +5V +12V +5VSB -12V
Max.(Amps) 22A 22A 70.9A 2.5A 0.3A
Min.(Amps) 0A 0A 0A 0A 0A
Range (%) ±2.5% ±2.5% ±2.5% ±5% ±5%
Line Reg.(%) ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p) 30mV 30mV 30mV 30mV 50mV
Power density
471W per liter
Color
Black (lead-free paint)
Combined +3.3V & +5V
120W
Combined +12V
850W
Input Voltage
90V~264V
Input Frequency Range
47Hz ~ 63Hz
PFC
Active PFC.(PF>0.95 at Full Load)
Efficiency
87%~90% at 20%~100% loading
MTBF
100,000 hours
Operating temperature
0°C ~ 40°C
Protection
Over current protection
Over power protection
Over voltage protection
Over temperature protection
Under voltage protection
Short circuit protection
Connectors
1 x 24 / 20-Pin motherboard connector(600mm)
1 x 8 / 4-Pin EPS / ATX 12V connector(750mm)
1 x 8 / 4-Pin EPS / ATX 12V connector(550mm)
4 x 8/6-Pin PCIE connector(”550mm/150mm” x 2)
2 x 8/6-Pin PCIE connector (550mm x 2)
8 x SATA connector("600mm /150mm / 150mm / 150mm" x 2)
6 x 4-Pin Peripheral connector(”600mm / 150mm / 150mm” x 2)
2 x 4-Pin Floppy connector(100mm x 2)
Cooling System
Single 120mm silent fan
Form factor
Noise Level
18 dBA minimum
Dimension
150 mm (W) x 86 mm (H) x 140 mm (D)
5.91" (W) x 3.39" (H) x 5.51" (D)
Weight
1.55 kg
Certification
80 PLUS Gold
Other
GPU Support list
Compatible with ATX12V v2.4
Brand SILVERSTONE
Weight 1.550000
