SilverStone ST70F-ES230 700W 80 Plus Power Supply

AED 250.00

In stock

SKU
ST70F-ES230

■ High efficiency with 80 PLUS certification

■ 24/7 continuous power output with 40℃ operating temperature

■ Class-leading single +12V rail

■ Active PFC Circuitry

■ PCI-E 8pin and PCI-E 6pin connector support

■ Silent running 120mm fan with 18dBA

heart
Wish List
chart-bar
Compare

SilverStone ST70F-ES230 700W 80 Plus Power Supply

-

Designed for 80 PLUS level of efficiency to reduce wasted heat and save on electricity.

Built-in 120mm fan has excellent airflow and low noise, perfect for quiet home or office use.

Powerful single +12V rail design, perfect for future high-end component upgrades or overclocking.

Compact 140mm depth design for easier installation in small from factor.



■ High efficiency with 80 PLUS certification

■ 24/7 continuous power output with 40℃ operating temperature

■ Class-leading single +12V rail

■ Active PFC Circuitry

■ PCI-E 8pin and PCI-E 6pin connector support

■ Silent running 120mm fan with 18dBA

SKU ST70F-ES230
GTIN 4710007223338
Specifications
Model No.
SST-ST70F-ES230
Max. DC Output
700W
Power density
388W per liter
Load Range

+3.3V +5V +12V +5VSB -12V
Max.(Amps)
22A 22A 54A 2.5A 0.3A
Peak (Amps)
/ / / / /
Min.(Amps)
0A 0A 0A 0A 0A
Range (%)
±5% ±5% ±5% ±5% ±10%
Line Reg.(%)
±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p)
50mV 50mV 120mV 50mV 120mV
Color
Black(Lead-Free Paint)
Combined +3.3V & +5V
130W
Combined +12V
648W
Input Voltage
180V~264V
Input Frequency Range
47Hz~63Hz
PFC
Active PFC(PF>0.9 at full load)
Efficiency
82% ~ 85% at 20% ~ 100% loading
MTBF
100,000 hours
Operating temperature
0°C ~ 40°C
Protection
Over power protection

Over voltage protection

Short circuit protection
Connectors
1 x 24 / 20-Pin motherboard connector(500mm)

1 x 8 / 4-Pin EPS / ATX 12V connector(750mm)

4 x 8 / 6-Pin PCIE connector("500mm / 150mm" x 2)

4 x SATA connector("500mm / 150mm" x 2)

3 x 4-Pin Peripheral connector(500mm / 150mm / 150mm)

1 x 4-Pin Floppy connector(500mm / 150mm / 150mm / 150mm)
Cooling System
Single 120mm silent fan
Form factor
Noise Level
18 dBA minimum
Dimension
150 mm (W) x 86 mm (H) x 140 mm (D)
5.91" (W) x 3.39" (H) x 5.51" (D)
Weight
1.43 kg
Certification
80 PLUS
Other
GPU Support list
Compatible with ATX12V v2.4
Brand SILVERSTONE
Weight 1.430000
