Msi MEG Z790 ACE DDR5 LGA 1700 E-ATX Intel Motherboard | 911-7D86-001

Out of stock

SKU: 911-7D86-001

The MEG series is revealed as a legend that represents the ultimate elegance in gaming.
With the determination of transcending current gaming products, the flagship models push the limits of what an extreme gaming series can be.

Wish List

Compare

Msi MEG Z790 ACE DDR5 LGA 1700 E-ATX Intel Motherboard | 911-7D86-001

Stacked Fin Array Design
Stacked fin array design enlarges up to 50% heat dissipation, provides the maximum surface of heat dissipation.

Direct Touch Cross Heat-Pipe
The U-shape dual heat-pipe connect three MOS heatsinks to enlarge the surface of heat dissipation.

Double-Sided M.2 Shield Frozr
Double-sided M.2 thermal solution keep M.2 SSDs safe while preventing throttling, making them run cooler and faster.

Aluminium Backplate
The aluminium baseplate cool down the MOSFET temperature with dedicated thermal pads.

7W/mK Thermal Pad
High quality 7W/mK MOSFET thermal pads and extra choke thermal pads ensure all cores running in high performance.

Enlarged PCH Heatsink
MSI replaced the PCH fan with enlarged heatsink design to reduce dust and noise as well as maintain high heat dissipation efficiency.

SKU	911-7D86-001
GTIN	4711377025546
Specifications	CHIPSET INTEL Z790 CPU SUPPORT Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors SOCKET LGA 1700 MEMORY 4x DDR5 UDIMM, Maximum Memory Capacity 192GB ONBOARD GRAPHICS 1x Type-C DisplayPort Supports a maximum resolution of 4K 60Hz ONBOARD THUNDERBOLT Thunderbolt chip JHL8540 2x Thunderbolt4 (USB-C) ports Q’ty EXPANSION SLOT 3x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 5.0 supports up to x8 (From CPU) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) STORAGE 5x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260 devices M.2_4 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280 devices M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 22110/2280/2260 devices 6x SATA 6G USB 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Front) 7x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Rear) 2x USB 3.2 Gen2x2 Type C (Front) LED FEATURE 1x EZ LED Control switch 4x EZ Debug LED 1x 2-Digit Debug Code LED
Brand	MSI
Weight	4.500000
Chipset Brand	Intel Z790
Socket	Intel LGA 1700
Form Factor	E-ATX
