Asus TUF B550-Plus Gaming WiFi AMD AM4 ATX Gaming Motherboard | 90MB15D0-MVAAY0

Out of stock

SKU: 90MB15D0-MVAAY0

TUF GAMING B550-PLUS WIFI II distills essential elements of the latest AMD platform and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive set of cooling options, this motherboard delivers rock-solid performance with unwavering gaming stability.

Wish List

Compare

Asus TUF B550-Plus Gaming WiFi AMD AM4 ATX Gaming Motherboard | 90MB15D0-MVAAY0

AMD AM4 socket
Ready for Ryzen 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors

Enhanced power solution
8+2 DrMOS power stages, ProCool sockets, military-grade TUF components, and Digi+ VRM for maximum durability

Comprehensive cooling
VRM heatsink, PCH fanless heatsink, Dual M.2 heatsink, hybrid fan headers and Fan Xpert 4 utility

Next-gen connectivity
PCIe 4.0 M.2, USB 3.2 Gen 2 Type-A and Type-C, Thunderbolt™ 3 header support

Made for online gaming
Wi-Fi 6, 2.5 Gb Ethernet, and TUF LANGuard

AI noise-canceling microphone
provides crystal-clear in-game voice communication

SKU	90MB15D0-MVAAY0
GTIN	4711081338413
Specifications	CPU AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series Desktop Processors Refer to www.asus.com for CPU support list. Chipset* B550 Memory 4 x DIMM, Max. 128GB, DDR4 4866(OC)/4800(OC)/4600(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz, Un-buffered Memory* Dual Channel Memory Architecture Graphics 1 x DisplayPort 1.2 1 x HDMITM 2.1(4K@60HZ) Graphics specifications may vary between CPU types. Expansion Slots* AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors 1 x PCIe 4.0 x16 slot (supports x16 mode) AMD Ryzen™ 5000 G-Series/ 4000 G-Series Desktop Processors 1 x PCIe 3.0 x16 slot (supports x16 mode) AMD B550 Chipset 1 x PCIe 3.0 x16 slot (supports x4 mode)* 3 x PCIe 3.0 x1 slot* PCIE 3.0 X16_2 runs x1 mode when any of the PCIe 3.0 x1 slots is occupied. Storage* Supports 2 x M.2 slots and 6 x SATA 6Gb/s ports Wireless & Bluetooth 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) + BT5.2 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Supports 2.4/5GHz frequency band Bluetooth v5.2*
Brand	ASUS
Weight	0.890000
Chipset Brand	AMD B550
Socket	AMD AM4
Form Factor	ATX
