Synology M.2 SSD & 10GbE Combo Adapter Card | E10M20-T1

Synology M.2 SSD & 10GbE Combo Adapter Card | E10M20-T1

the E10M20-T1 M.2 SSD & 10GbE Combo Adapter Card from Synology helps you simultaneously boost I/O performance and network bandwidth using one PCIe expansion slot on your NAS. This card two M.2 slots, each of which supports an M.2 2280 or 22110 SSD, plus a 10Gb Ethernet port that also supports speeds of 5 Gb/s, 2.5 Gb/s, 1 Gb/s, and 100 Mb/s. The E10M20-T1 also features a PCIe 3.0 x8 host bus interface and a low profile/full height form factor.

General Features
10GbE Ready
Achieve multi-gig Ethernet transmission speeds of up to 10 Gb/s.

NVMe Enabled
Accelerate random I/O performance with the dual M.2 2280/22110 NVMe SSD slots.

Dedicated Cache Slots
Free up primary drive bays for data storage. With the E10M20-T1, you won't need to use 2.5" drive bays to create an SSD cache, since it installs into a PCIe slot.

Matches with Synology SNV3000 Series NVMe SSDs
Install a Synology SNV3000 Series NVMe SSD on the E10M20-T1 adapter card for fast and streamlined cache acceleration, and take full advantage of Synology SSD's enterprise-grade endurance, performance, and reliability with your Synology NAS.

Compatibility - NVMe SSDs
SA Series
SA6400, SA3610, SA3600, SA3410, and SA3400
23 Series
RS2423RP+ and RS2423+
22 Series
RS822RP+, RS822+, DS3622xs+, and DS2422+
21 Series
RS4021xs+, RS3621xs+, RS3621RPxs, RS2821RP+, RS2421RP+, RS2421+, RS1221RP+, and RS1221+
20 Series
RS820RP+ and RS820+
19 Series
DS2419+ and DS1819+
18 Series
RS3618xs, RS2818RP+, DS3018xs, and DS1618+
17 Series
RS18017xs+, RS4017xs+, RS3617xs+, RS3617RPxs, DS3617xsII, and DS3617xs
